Irrigation Nashville TN: Sprinkler System Design and Installation

Nashville Pro Landscape designs and installs irrigation systems in Nashville and across Davidson County: sprinkler zones for turf, drip for beds, smart controllers and seasonal service. A new six to eight zone system runs $3,000 to $6,000. Call for a free on-site estimate, and we’ll measure your water pressure before we draw anything.

Call (615) 334-9088 or request a free quote. Already have a system that needs fixing? That’s our sprinkler repair page. This one covers new systems, added zones, drip, controllers and service agreements.

How much does an irrigation system cost in Nashville?

A new residential irrigation system in Nashville runs $3,000 to $6,000 for six to eight zones. Zones price at $500 to $850 each, drip irrigation for beds runs $1,500 to $4,000, and a smart controller upgrade runs $200 to $500. Trenching through limestone-heavy ground is what drives the spread from one lot to the next.

The install and upgrade figures match our 2026 cost guide. The backflow fee is Metro Water Services’ posted figure and Metro notes it can change. Inside those ranges, your number depends on:

• Zone count. Zones are set by how much water your supply can deliver at once, not by lot size alone. Low pressure means more, smaller zones.
• Rock. Nashville’s soil is often shallow over limestone bedrock. A trench that hits ledge takes longer, and sometimes the line has to route around it.
• Turf versus beds. Open lawn is the cheap part to cover. Beds, foundation plantings and trees on drip take more fittings and more hand work.
• What’s in the way. Driveways and walks to bore under, mature tree roots to avoid, and existing landscape to put back.
• The backflow assembly. Metro requires one on every irrigation system, installed by a plumber under a permit. That’s a separate trade on the job.

What does our irrigation installation process look like, step by step?

It runs in nine steps: measure the water supply, design the zones, price it in writing, clear utilities and permits, set the backflow assembly, trench and pipe, set heads and drip, program the controller, then test every zone with you standing there. Most residential installs take a few days on site once the locates are done.

1. Site visit and measurements. We read static pressure and flow at the house, note the meter size, and map sun, shade, slope, turf type and beds. You decide which areas get water and which don’t. About an hour on site.
2. Design. The numbers from step one set how many heads each zone can carry. Turf and beds go on separate zones, and so do full-sun and shade areas, because they don’t want the same amount of water. You get a zone map.
3. Written quote. Priced by zone, with the controller, drip and backflow work shown as their own lines. You decide whether to build it all at once or phase it, front yard first.
4. Locates and permits. Tennessee 811 asks for at least three working days’ notice before digging. In Davidson County the backflow preventer needs a permit from Metro Codes, issued to the plumber, with a cross-connection review through Metro Water Services for residential projects.
5. Backflow assembly. The plumber sets it where Metro wants it: directly behind the meter, outside the house, at least a foot above the 100-year floodplain, where the ground drains away from it.
6. Trench and pipe. Mainline and laterals go in, valves get grouped in boxes you can find later, and sleeves go under walks and drives. Sod is lifted and set back where we can.
7. Heads and drip. Rotors or sprays on turf, spaced so each head’s throw reaches the next head. Drip tubing in the beds, under the mulch.
8. Controller and sensor. Each zone gets its own run time based on plant type, sun and soil. A rain sensor or weather-based controller keeps it from running after a storm.
9. Test, inspect, walk through. Every zone runs while we adjust arcs and check for leaks. Metro Water Services does the initial backflow inspection. You get the zone map, the schedule, and a lesson on the controller. Plan on an hour for the walk-through.

What kind of irrigation system fits a Nashville yard?

Most Nashville yards want a mix: rotors or spray heads on the lawn, drip on the beds and around trees, and a controller that can treat each zone differently. The lawn is usually tall fescue, which needs steady water through July and August, and the soil is slow-draining clay that can’t take it fast.

• Rotors cover open turf with a slow, even stream. They’re the right call for bigger lawn areas.
• Spray heads handle small or narrow strips of grass. They put water down fast, so on clay they need short run times.
• Drip puts water at the root zone in beds without wetting leaves or mulch. It’s also the easiest zone to extend when the planting changes.
• Separate zones for sun and shade. In the transition zone you often have fescue in the shade and Bermuda or Zoysia in full sun on the same lot. They peak at opposite times of year and shouldn’t share a valve.
• Cycle and soak. Central Basin clay packs tight and sheds water once the surface is wet. Splitting a zone’s run into shorter cycles with a pause between them gets the water into the ground instead of the gutter.

Our Nashville grass types guide covers which turf you likely have, and the soil and drainage guide explains why the clay behaves the way it does.

Do you need a permit or a backflow preventer for irrigation in Davidson County?

Yes to the backflow preventer, and it comes with a permit. Metro Nashville requires backflow preventers on irrigation and sprinkler systems, says the installation requires a licensed plumber, and issues the permit to that plumber. Metro Water Services then inspects the device when it goes in and every year after.

• Why it exists. A pressure drop in the main can pull water backward out of an irrigation line, and that water has been sitting in the yard with fertilizer and soil. The assembly stops it from reaching the drinking supply.
• What’s allowed. Metro doesn’t allow lead devices, and the assembly has to be on the approved-assemblies list maintained by the University of Southern California.
• Where it goes. Directly behind the meter, so nothing branches off ahead of it. Any other spot needs a variance from Metro’s variance committee.
• What it costs to keep. Metro’s annual inspection is $50 per device on the water bill. A failed device gets a deadline, from immediate to ninety days depending on the hazard, and each re-test is $42.
• Who does what. We design and build the irrigation side. The backflow assembly is the plumber’s work under the plumber’s permit, and we schedule our work around it.

Outside Metro’s water system the rules shift with the utility. Brentwood’s water department allows only reduced-pressure assemblies on irrigation and requires testing at least once a year by a state-certified tester. Franklin’s inspectors test household devices yearly and put the fee on the water bill. Harpeth Valley Utilities District serves parts of Davidson, Williamson and Cheatham counties. Tell us who bills your water and we’ll check that utility’s rules before we quote.

How much water will an irrigation system use, and what will it cost?

Actively growing fescue needs 1 to 1.5 inches of water a week, which University of Tennessee Extension puts at about 630 to 945 gallons per 1,000 square feet. On a 5,000 square foot lawn that’s roughly 3,150 to 4,725 gallons in a week with no rain, or about 4 to 6 CCF on a Metro bill.

Metro Water Services bills by the CCF, which is 748 gallons. On its 2025 residential rate table the first 2 CCF carry no volume charge, 3 to 6 CCF cost $4.08 each, 7 to 10 cost $4.90, and everything past 10 costs $6.13. So in a dry summer week, that 5,000 square foot lawn adds somewhere around $26 to $39 in water at the top rate, before Metro’s fixed charges and fees. Rain knocks that down, and Nashville gets about 47 inches of it a year.

Two things work in your favor. From April through November, Metro automatically caps residential sewer charges at the winter-quarter average plus 30 percent, because lawn water never reaches the sewer. Metro calls it the sprinkler credit. And a system that’s zoned right doesn’t water the driveway, which a hose-end sprinkler usually does.

Are smart controllers worth it in Nashville?

Yes, for most yards. A smart controller upgrade runs $200 to $500, and its whole job is to skip or shorten watering when the weather has already done the work. In a place that gets about 47 inches of rain a year but still dries out in July and August, that matters.

A fixed timer waters on Tuesday whether it stormed on Monday or not. On fescue that’s more than wasted water. Our lawn calendar starts brown-patch watch in June, and keeping fescue wet when it doesn’t need water only helps the disease along. A controller that reads the weather, or a plain rain sensor wired to the timer you have, fixes most of that.

A smart controller also makes it simple to follow Metro’s request. In a notice dated August 28, 2024, Metro Water Services asked customers with automatic systems to water no more than three days a week, odd addresses Monday, Wednesday and Friday, even addresses Tuesday, Thursday and Saturday, between 7 p.m. and 4 a.m. It’s voluntary, and Metro says tighter limits could follow if peak demand doesn’t come down. Our watering guide has the details.

What does an irrigation service agreement normally cover?

A seasonal service agreement is a maintenance contract. It normally covers a spring start-up, a mid-season check, a fall blowout, and seasonal controller changes, with repairs quoted separately at a stated rate. It isn’t a warranty, and the two shouldn’t be confused when you’re comparing paperwork from different companies.

If you’re reading agreements from any irrigation company in Nashville, these are the terms worth finding in writing:

• Visits. How many per year, and what gets done on each. Spring start-up after the last frost, around April 10 here. A summer coverage check. Blowout before the hard freezes, in November.
• What’s included and what’s billed. Adjusting heads and reprogramming are usually included. Parts and digging usually aren’t. Look for the repair rate, not just the visit price.
• Freeze terms. Who’s responsible if a line or the backflow assembly cracks after the company winterized it, and what happens if you skipped the blowout.
• Backflow. In Metro’s system the annual inspection is done by Metro Water Services or its contractor and billed by Metro. An agreement shouldn’t charge you for that inspection as though the company performs it.
• Parts coverage. Heads, valves and controllers carry their manufacturers’ own coverage terms. Ask which brand is going in and get the manufacturer’s paperwork.
• Workmanship terms. Whatever the installer promises about its own work should be written into the contract with a time period. If it isn’t written down, it isn’t a term.
• Cancellation and renewal. Whether it renews on its own, and how you stop it.

Ask us for the service terms with your estimate and read them before you sign, the same as you would with anyone else.

When is the best time to install irrigation in Nashville?

Late summer, ahead of fall seeding, is the best window. September is the prime month to aerate and overseed fescue in Nashville, and new seed needs light, frequent water to come up. A system that’s in and tested by then does that job for you. Spring, before the July heat, is second best.

Sod works the same way. New fescue sod runs $1.50 to $3.00 per square foot installed, and it’s a lot of money to lose to a dry week. If a new lawn is in the plan, the irrigation goes in first, the grading gets fixed second, and the sod or seed goes down last.

Winter installs are possible when the ground isn’t frozen, but a system finished after the average first frost, around October 28, gets blown out before it ever runs a full season.

What does a typical Nashville irrigation project look like?

These are typical scopes, written as examples and not as jobs we’re claiming to have done. The price ranges come from our published cost guide. Your own design starts with the pressure reading at your house, and we’ll tell you which of these your yard looks most like.

• Typical subdivision lot, front and back lawn. Six to eight zones, mostly rotors, one or two drip zones on the foundation beds, smart controller. A few days on site. $3,000 to $6,000.
• Typical front-yard-only first phase. Three or four zones covering the lawn and street-side beds, with the mainline stubbed out for the back yard later. Priced by the zone at $500 to $850.
• Typical bed conversion. An older system where spray heads are soaking shrubs and mulch. The bed zones get converted to drip and the lawn zones stay. $1,500 to $4,000 depending on how much bed there is.
• Typical rocky lot. Shallow soil over limestone, which is common across the Central Basin. Lines route along the easier ground, more of the planting goes on surface drip, and the quote sits toward the top of the per-zone range.
• Typical controller and sensor upgrade. The pipe and heads are fine but the timer is a dial with no rain shutoff. New controller, new sensor, zones reprogrammed. $200 to $500.

Should you replace an old system or repair it?

Repair it if the pipe and valves are sound. Rebuilding one bad zone runs $500 to $850 against $3,000 to $6,000 for a new system, so replacement only makes sense when several zones are leaking or the layout never covered the yard. Heads, valves, leaks, start-ups and blowouts are on our sprinkler repair page.

The middle path is common: keep the mainline and valves, rebuild the worst zones, convert beds to drip, and swap the controller. See sprinkler repair in Nashville for repair pricing and the blowout schedule.

How does irrigation tie in with drainage, design and hardscape?

Irrigation is the one system in the yard that touches all the others, so it’s cheapest to plan it with them. Lines need to be sleeved before a patio is poured, drip zones need to match the planting plan, and a yard with a drainage problem needs that fixed before more water gets added.

• Landscape design: new beds almost always mean reworked drip zones.
• Hardscaping: sleeves go under walks and patios before the base goes down.
• Drainage solutions: standing water on clay is a grading problem, and irrigation makes it worse until it’s fixed.
• Lawn mowing and leaf removal: crews flag clipped or buried heads when they see them.

Where in Davidson County and Middle Tennessee do you install irrigation?

We install and service irrigation across Nashville and Davidson County, including Green Hills, Bellevue, East Nashville and Old Hickory, and out through Brentwood, Franklin, Hendersonville, Mt. Juliet, Smyrna and La Vergne. Permit and backflow rules follow your city and your water utility, so we confirm both before quoting.

Local pages: Lebanon, La Vergne, Goodlettsville, Columbia and Thompson’s Station, or see all the areas we serve.

Ready for a design and a number? Call (615) 334-9088 or get a free on-site estimate. We’ll bring the pressure gauge.
